Description
| Type of material | PC/ABS Alloy, PA 66 GF13 HSL for elastic clips |
| Standard color | RAL 7035, other colors on request |
| Protection degree | IP54, according to EN 60529 Std Type 12 according to UL 508 Std |
| Fixing system | by elastic clips |
| Plate thickness | from 1.3 mm to 3.7 mm (up to 4 mm with cut-out max tolerance) |
| Storage temperature | from -40°C to +70°C |
| Motor Lifetime L10 at 40°C | 40,000 h |
| Motor protection | Thermal |
| Electrical connection | by screwless terminal block 3 poles L-N-PE, 2.5 mm² (20-14 AWG) |
| Earth connection | by PE pole |
| Appliance class | Class l |
