Description
Casing material | Black fibreglass reinforced plastic (PBT) UL 94V-0 |
Impeller material | Black fibreglass reinforced plastic (PBT) UL 94V-0 |
Protection degree | IP20, according to EN 60529 standard |
Fixing system | 4 holes Ø4.4 mm |
Motor protection | Impedance |
Storage temperature | from -40°C to +70°C |
Rated temperature range | from -10°C to +70°C |
Lifetime L10 at 40°C | 70,000 h ball bearing; 22,000 h sleeve bearing; 40,000 h hypro bearing |
Electrical connection | 2 leads 26AWG UL 1007, 300 mm long |
Approvals | CE; UL E223195 |
