Description
| Type of material | ABS/PC alloy |
| Standard color | RAL 7032, RAL 7035 and RAL 9005 – other colors on request |
| Protection degree | IP54, according to EN 60529 Std; Type 12, according to UL 508 Std |
| Fixing system | by elastic hooks, otherwise by four 2.2 mm self-threading screws |
| Plate thickness | from 1.5 mm to 2.2 mm |
| Storage temperature | from -40°C to +70°C |
| Motor Lifetime L10 at 40°C | 70,000 h |
| Motor protection | Overcurrent, reverse polarity |
| Electrical connection | by terminal block 2 poles +, – 2.5 mm² (12 AWG) |
| Appliance class | Class lll |
| Type of filter media | Thermo-linked progressive structure syntetich fibre |
| Filtering class | Class G3, according to EN 779 |
| Dust retention capacity | 600 g/m^2 |
| Note | Filter media is washable for about 10 times |
| Approvals | CE, UL E237844 |
