Description
| Type of material | PC/ABS Alloy, PA 66 GF13 HSL for elastic clips |
| Standard color | RAL 7035, other colors on request |
| Protection degree | IP54, according to EN 60529 Std Type 12 according to UL 508 Std |
| Fixing system | by elastic clips |
| Plate thickness | from 1.3 mm to 3.2 mm |
| Storage temperature | from -40°C to +70°C |
| Motor Lifetime L10 at 25°C (approx.) | 57,000 h |
| Motor protection | Impedance |
| Electrical connection | by screwless terminal block 3 poles L-N-PE, 2.5 mm² (20 – 14 AWG) |
| Earth connection | by PE pole |
| Appliance class | class l |
| Type of filter media | Thermo-linked progressive structure synthetic fibre |
| Filtering class | Class G3, according to EN 779 |
| Degree of separation | 85% – DIN 24185 |
| Dust retention capacity | 600 g/m^2 |
| Note | Filter media is washable about 10 times |
| Approvals | CE; UL E237844; CSA |
