Description
| POWER SUPPLY | 80..265 Vac (-H versions) 10..40 Vdc/19-28 Vac (-L versions) |
| POWER TRANSDUCERS | Max 18 V, 25 mA |
| MAX CONSUMPTION | 1,5 W |
| INSULATION | 1.500 Vac |
| NOISE REJECTION | 50..60 Hz |
| COMMUNICATION INTERFACE | RS485, ModBUS RTU, max 32 nodes (optional board) |
| MEMORY | Data memory, 10 years EEPROM |
| OPERATING TEMPERATURE |  -10..+60°C |
| CASE | PPO self-extinguish DIN 43700 |
| FRONT PROTECION DEGREE | IP65 |
| TERMINALS | Removable, pitch 3,5 – 5,08 mm |
| DIMENSION WXHXD | 98,5×44,5×90,5 mm |
| PANEL HOLE DIMENSION | 96,5×48,5 mm |
| WEIGHT | 200 g |
| SETTINGS | Front keys, password protect access |
| ANTI-BUMP FILTER | From 0 to 255 s |
| CALIBRATION | Yes, factory setting |
| MANUAL MODE | Setpoint value visualization with output retransmission |
| AUTOMATIC MODE | Measured value visualization with output scaling and retransmission |
| SPECIAL FUNCTIONS | Manual / Automatic mode, signal generator, anti-bump filter |
| NORMS | EN 61000-6-4, EN 61000-6-2, EN 61010 |
| APPROVALS | CE |
| DISPLAY | 4-digit LED, adjustable contrast |
| STATUS INDICATORS | 2 LEDs (Automatic / Manual) |
| BUTTONS | 3 control buttons |
| ACCURACY | 0,1% |
| STABILITY | 0,01%/K |
| LINEARITY | <0,1% |
| EMI | <1% |
| INPUT CHANNELS | 1 |
| INPUT CHANNELS TYPE AND RANGE / RESOLUTION | Voltage: 0..10 V (impedance 100kΩ) Current (active/passive): 0..20mA (impedance 20Ω) Potentiometer: 1..100kΩ (with 330Ω parallel resistor, exciting current 1,1mA) 14 bit, 10.000 points |
| SAMPLING FREQUENCY | 2 Hz |
| RESPONSE TIME | 700 ms |
| OUTPUT CHANNELS | 1 |
| OUTPUT CHANNELS TYPE AND RANGE / RESOLUTION | Tensione: 0..10 V (min 1KΩ) Current (active/passive): 0..20 / 4..20 mA (max 500Ω) 2ÎĽA / 1mV – 10.000 points |
