Description
| Type of material | ABS/PC alloy |
| Standard color | RAL 7032, RAL 7035 and RAL 9005 – other colors on request |
| Protection degree | IP54, according to EN60529 standard Type 12, according to UL 508 Std |
| Fixing method | by elastichooks, otherwise by four 4.8 mm self-threading screws |
| Plate thickness | from 1.5 mm to 2.2 mm |
| Storage temperature | from -30°C to +75°C |
| Motor Lifetime L10 at 25°C | 62,000 h 50Hz and 70,000 h 60 Hz for 115V; 57,500 h 50Hz and 70,000 h 60 Hz for 230V |
| Working class of capacitor | Class B |
| Motor protection | Thermal |
| Electrical connection | by screwless terminal block 3 poles L-N-PE, 2.5 mm² (12 AWG) |
| Earth connection | by PE pole |
| Appliance class | Class I |
| Type of filter media | Thermo-linked progressive structure synthetic fibre |
| Filtering class | Class G3, according to EN 779 |
| Degree of separation | 85% – DIN 24185 |
| Dust retention capacity | 600 g/m² Note: filter media is washable for about 10 times |
| Approvals | CE |
