Description
| Type of material | PC/ABS alloy |
| Standard color | RAL 7032, RAL 7035 and RAL 9005 – other colors on request |
| Protection degree | IP54, according to EN 60529 Std |
| Fixing system | by elastic hooks, otherwise by four 4.8 mm self-threading screws |
| Plate thickness | from 1.5 mm to 2.2 mm |
| Storage temperature | from -40°C to +70°C |
| Motor Lifetime L10 (approx.) | at 40°C 40,000 h |
| Motor protection | thermal |
| Electrical connection | by terminal block 3 poles L-N-PE |
| Earth connection | by terminal block, PE pole |
| Appliance class | Class l |
| Type of filter media | thermo-linked progressive structure synthetic fibre |
| Filtering class | class G3, according to EN 779 |
| Degree of separation | 85% – DIN 24185 |
| Dust retention capacity | 600 g/m^2 |
| Note | Â filter media is washable for about 10 times |
