Call for Price
Fandis “D04F” Standard DC Costech Fans
Type : Ball bearing
Rated Voltage : 12 VDC
Rated Temperature : from (-20 to +70) °C
Standard Packing : 1 unit
| Casing material | Black fibreglass reinforced plastic (PBT) UL 94V-0 |
| Impeller material | Black fibreglass reinforced plastic (PBT) UL 94V-0 |
| Electrical connection | 2 leads 28AWG UL 1571, 140 mm long |
| Rated temperature range | from -20°C to +70°C (Ball bearing) |
| from -10°C to +60°C (Sleeve bearing) | |
| Lifetime L10 (Ball bearing) | 70,000 h at 40°C |
| 40,000 h at Max temperature | |
| Lifetime L10 at 40°C (Sleeve bearing) | 50,000 h at 40°C |
| 35,000 h Max temperature |
| Weight | 0.024 kg |
|---|
