Description
| Impeller material | Fibre reinforced plastic (PA66) blades |
| Casing material | Aluminium alloy die casting UNI5076 |
| Fixing system | No 4 holes Ø4.5 |
| Motor protection | Thermal |
| Rated temperature range | from -20°C to +70°C |
| Motor Lifetime L10 at 25°C (approx.) | 63,000 h |
| Insulation class | F |
| Working class of capacitor | Class B for 115V model |
| Class A for 230V model | |
| Electrical connection | by screwless terminal block 2.5 mm² (20 – 14 AWG): |
| 3 poles L-N-PE for 115/230Va.c. models; | |
| 4 poles L1-L2-L3-PE for 400Va.c. models |
