VISUAL6

Call for Price

SENECA 7″ HMI panel touchscreen with 2 ETH ports, HMI/webserver replica version, CHROMIUM function

SENECA expands its offer for the Z-PC with VISUAL, the new range of operator panels suitable for the most common industrial controllers and supervisory/automation systems.
VISUAL6 is a 7″ HMI equipped with a powerful 600 Mhz Cortex A8 CPU, 128 MB of RAM, high quality display LED backlights with a 800×480 pixel resolution, 2 serial ports (Nr. 1 RS232 and Nr. 1 RS485) and 2 ethernet ports.

Description

ORDER CODE : VISUAL6
DESCRIPTION: 7″ HMI panel touchscreen with Ethernet port, HMI/webserver replica version, CHROMIUM function
POWER SUPPLY: 24 Vdc
POWER CONSUPTION: 350 mA @ 24 Vdc
DISPLAY: 7” TFT LCD, 800×480 px resolution, 16M colors
TOUCHSCREEN: Resistive 4 wires
CONNECTIONS: Nr. 1 USB Client 2.0 port
Nr. 1 RS232 port
Nr. 1 RS232/RS485 port
Nr. 2 Ethernet port 10/100/1000 BaseT
OPERATING TEMPERATURE: 0..+50°C
PROTECTION DEGREE: NEMA4 / IP65
PROCESSORE: 32 bit RISC Cortex A8 600 MHz
FLASH MEMORY: 128 MB
RAM: 128 MB
RTC: built-in
DIMENSIONS (WXHXD): 200,4×146,5×34 mm
WEIGHT: 600 g
STANDARD: CE

Additional information

Weight 0.6 kg

Download

Catalog – HMI Visual Series
