Description
Heating element | PTC thermistor, self regulating |
Heat sink | black anodised extruded aluminium profile |
Cover material | black anodised aluminium |
Method of mounting | snap-on fixing on RAIL 35mm EN 50022 |
Rated temperature range | from -30°C to +50°C |
Storage temperature range | from -40°C to +70°C |
Protection degree by heaters | IP20 |
Electrical connection | by 3 poles cable L-N-PE |
External cable | 3 x 0.50 mm² cable 500 mm lenght, with silicone rubber insulation and external sheath |
Appliance class | class l |
Rated frequency | 50/60 Hz |
Max voltage | 265 V a.c./d.c. |
Applicable standards | EN 60335-1 |
Approvals | CE |
